每小时100-120吨处理量 破碎制砂水洗设备、砂金设备工作现场

洗沙设备

洗沙设备

【破碎制砂水洗设备、砂金设备流程概述】

原料通过工程车辆送入料仓,通过料斗底部悬挂式振动给料机均匀给料进入上料输送机,由上料输送机送入滚筒筛内进行筛选分级为:细料与粗料两种规格:

粗料进入一台反击式制砂机内进行破碎;细料通过一条溜槽排入破碎机底部与破碎后的物料汇合,然后一起依次进入两台轮式洗砂机内进行二次清洗,清洗后的成品料由成品料输送机输送至成品料区域;

轮式洗砂机溢流口排出的废水与细砂通过管道排入一料箱内,通过一台沙泵打入细沙回收机内进行细砂回收与脱水,脱水后的细砂与成品料混合通过成品料输送机输送至成品料区域。

Technical process

Raw material get into feed hopper then into transport conveyor well distributed with work of vibration feeder,then into trommel screen to be classified into 2 size:the big(coarse) material and fine size material:

The big size one into one set of sand making machine(Impact type)to be crushing the crushed material with fine size material together into 2set of wheel bucket type sand washer for the 2nd time washing,then final production get and transported to destination by conveyor;

The fine sand discharged with scrap water into mineral box through the pipe by wheel bucket sand washer,then to be feed into fine sand recover machine by sand pump,the final production clean sand get and transported to destination by transport conveyor.

【破碎制砂水洗设备、砂金设备技术参数】
Detail parameter


名称
Production Name

规格
Specification

数量
Quantity

功率
Power

单价
Unit price

总价
Total price

备注
Remark

料仓
Feed hopper

3000*2200

1套

0.37

上料输送机
Transport conveyor

皮带宽度800 约15米
Belt width 800m,length about 15m

1套

11

滚筒筛
Trommel screen

内径1.3米,外径1.6米,净筛网长度3米
Inner diameter 1.3m,outer diameter 1.6m,screen mesh 3m

1套

11

轮式洗砂机
Wheel bucket sand washer

Ø2800*1800

2台

7.5*2

细砂回收机
Fine sand recover machine

1500*2750 ; 2.2KW*2
350#双旋流器
6寸沙泵+22KW电机+泵箱
6inch sand pump+22motor+mineral box

1台

26.4

成品料输送机
Final production transport conveyor

皮带宽度800mm,杆长15米
Belt width 800m,pole length about 15m

1套

11

制砂机
Impact sand making machine

800*1200

1台

110

水泵
Water pump

1台

7.5

配电箱
Electric box

含至设备电机线,不含变压器至设备电缆线
Including the electric wire excluding the cable

1套

-

总功率
Total power

184.77KW
